Hp agilent E4209B cell protocol processor 0-155MB/s
HP Agilent E4209B Cell Protocol Processor 0-155MB/s
The E4209B Cell Protocol Processor provides real-time and post-processing protocol testing features for the HP Broadband Series Test System (BSTS). The basic CPP assembly and system software can perform monitoring and simulation of ATM, F4 and F5 OAM, and AAL1 protocols. The CPP can be: configured with many different Line Interfaces at rates from 1.5 to 622 Mb/s, including: E1616A 1.5/45 Mb/s (DS1/DS3), E1610A 34 Mb/s (E3), E1695A 45 Mb/s (DS3), E1697A 155 Mb/s (STS-3c/STM-1) Optical, as well as E4219A ATM Network Impairment Emulation Module. The CPP can generate up to eight streams of user-defined ATM traffic. It also provides both real-time and post-processed measurements on ATM traffic. Measurements are automatically synchronized between devices in the test session.
This is a used, HP Agilent E4209B Cell Protocol Processor 0-155MB/s
* Provides protocol monitoring and simulation
* Runs optional test software for additional upper layer protocol testing
* Generates up to eight streams of user defined ATM test traffic
* Fast hardware based cell segmentation and re-assembly
