Tektronix TR502 operating & service manual + app note
Reproduction grade, HIGH RESOLUTION scan on CD-ROM
of the OPERATING & SERVICE MANUAL for the
TEKTRONIX TR502 TRACKING GENERATOR
Tektronix part number 070-1735-00.
Plus TR502 / 7L13 Application note
Another high quality Artekmedia scan. Typical of why Artekmedia is the largest supplier of "E-manuals" for the test equipment market place in the world.
* Diagrams, schematics, board part locators
* Electronic page numbers = actual manual page numbers (1-1, 1-2 etc)
* Hi resolution 600DPI scans of schematics
* FULL SIZE scans (11x17 and larger) of all foldout pages
* 60-pages in a 32-MB PDF format file
* Adobe Acrobat 7.0 or higher for reading
* 11 page application note featuring the use of the TR502 and 7L13 in 7000 series scopes
