1992 enshu dt-cl cnc drilling/tapping/machining center
1992! ENSHU DT-CL CNC DRILLING/TAPPING/MACHINING CENTER
Made in Japan by Enshu Limited.This is a CNC Vertical Drilling & Tapping Machining Center in working condition.Model #: DT-CLSerial #: 657Date of Manufacture: 1992
* Fanuc Series 21-M Control.
* 16-Station Carousel Automatic Tool Changer.
Surface Area: 27.5" x 15.75"
T-Slot Sizes: 0.975" wideTravels:
Y-Axis (Longitudinal): 15.7" (8.3" saddle stroke)
Z-Axis (Vertical): 11.8" (3.1 spindle head stroke)Spindle:
Spindle Speeds: 120 - 10,000 rpm
Spindle Speed Changes: One Step (continuous)
Distance from Pallet to Tip of Spindle: 4.7" - 16.5"
Spindle Bearing Diameter: 2.0"Automatic Tool Changer:
Pull Stud Type: MAS P30T-1 (45 degrees)
Magazine Tool Capacity: 16 tools
Maximum Tool Diameter: 3.1"
Maximum Tool Weight: 6.6 lbs. (44 lbs. total)
Tool Selection Method: Absolute Address Short Access
Tool Change Time (Tool-to-Tool): 3.1 seconds
Tool Change Time (Chip-to-Chip): 4.5 secondsMovement Rates:
Rapid Traverse (X/Y/Z): 1,417 ipm
Cutting Feed Rate: 0.04 - 196.9 ipm
Jog Feed Rate (21 steps): 0 - 157.5 ipmDrive Motors:
Spindle Motor (30 minutes / continuous): 10 / 7.5 Horsepower
Axis Feed Motors (X / Y): AC 0.85 kW
Axis Feed Motor (Z): AC 1.3 kW
Cutting Fluid Motor: 0.18 kW
Magazine Motor: 0.09 kWGeneral:
Cutting Fluid Tank Capacity: 100 liters
Lubrication Oil Tank Capacity: 20 liters
Electrical: 208 Volt, Three Phase
Overall Dimensions: 54" x 93" x 96" tall (as shown in pictures)Comes as shown in pictures.
