Hp agilent 8722D 40GHZ vector network analyzer opt 012
HP Agilent 8722D 40GHz Microwave Vector Network Analyzer
with OPT 012 (Direct Sampler Access)
Model: HP Agilent 8722D 40GHz Vector Network Analyzer with OPT 012, S/N: US3614049
This item is FACTORY CALIBRATED, in EXCELLENT cosmetic condtion, and passes all Self Test. It comes with Certificate of Calibration from Agilent as shown in the photos. This is a genuine, original piece of equipment. We offer 60 days warranty and 7 days ROR from receipt of goods.
Qty-1: HP Agilent 8722D 40GHz Vector Network Analyzer OPT 012
Qty-1: Certificate of Calibration from Agilent
Qty-1: Performance Test Record Report from Agilent
Qty-1: HP/Agilent 08503-60051 Interconnect Cable
**THERE ARE NO ADDITIONAL ACCESSORIES, PROBES, POWER CORDS, CDs, OR MANUALS INCLUDED WITH THIS UNIT.
HP Agilent 8722D 40GHz Vector Network Analyzer, Fully Calibrated by Agilent
Opt 012: Direct Sampler Access
HP/Agilent: 08503-60051 Interconnect Cable
The HP 8722D vector network analyzer characterizes RF and microwave components down to 50 MHz and up to 40 GHz. This analyzer includes a fast-sweeping synthesized source, S-parameter test set, tuned receiver, and large color display in a single package. The HP 8722D is an ideal choice for cost- and space-conscious engineers in research and development, manufacturing, incoming inspection, or quality assurance. High source power and high receiver sensitivity combine to give the HP 8722D 100 dB of dynamic range.
This unit is factory calibrated by Agilent, is in excellent cosmetic condition and is loaded with Option 012 (costs $2500 from Agilent)
* 50 MHz to 40 GHz frequency coverage
* New processor makes measurements and data transfers up to seven times faster
* Fast-sweeping, built-in synthesized source
* Integrated solid-state switching S-parameter test set
* Vector receiver, error correcton, time domain
* Up to 100 dB dynamic range
