New intel NH82801HBM 82801 SLA5Q south bridge ic ICH8-m
Model: NH82801HBM (South Bridge ICH8-M)
Original Code: SLA5Q
Intel I/O Controller Hub 8 (ICH8) Family Datasheet
For the Intel I82801HB ICH8, 82801HR ICH8R, 82801HH ICH8DH, 82801HO ICH8DO, 82801HBM ICH8M and 82801HEM ICH8M-E I/O Controller Hubs
This datasheet is for the Intel I82801HB ICH8, 82801HR ICH8R, 82801HH ICH8DH, 82801HO ICH8DO, 82801HBM ICH8M and 82801HEM ICH8M-E I/O Controller Hubs and is intended for Original Equipment Manufacturers and BIOS vendors creating Intel ICH8 Family-based products. This manual assumes a working knowledge of the vocabulary and principles of PCI Express*, USB, AHCI, SATA, Intel High Definition Audio (Intel HD Audio), SMBus, PCI, ACPI and LPC.
