New 12V dc 29A 350W switching power supply s-350-12
* Protections: Short circuit/ Overload
* Cooling by free air convection
* 100% full load burn-in test
* Low cost, hogh reliability
* AC input voltage range: 90~132VAC / 180~264VAC selectable by switch
* AC inrush current: Cold start, 25A at 115VAC, 50A at 230VAC
* DC adjustment range: 10% rated output voltage
* Overload protection: 105%~135% hiccup mode, auto-recovery
* Setup, rise, hold up time: 200ms, 50ms, 20ms at full load and 230VAC
* Withstand voltage: I/P-O/P:1.5KVAC, I/P-FG:1.5KVAC, 1 minute
* Working temperature: -10~60oC (refer to output derating curve)
* Safety standards: Design refer to UL1950
* EMC standards: Design refer to FCC part 15 J
* Connection: 9P/ 9.5mm pitch terminal block
