Valby 75" log grapple & R12 continuous rotator
Brand New GR75 Log Grapple with R12 Hydraulic Rotator Head.
* This Log Grapple & Hydraulic Rotator Head are available as a unit (as shown in photo) for installation on your own Supporting Structure, and it should be on a Significant Backhoe, Excavator, Truck Loader, etc!
* Your Significant Machine will need Dual Hydraulic Remotes.
* Maximum Gripping width is 74-3/4".
* Minimum Opening is 5-1/2" !
* Max Lift Capacity is 11,000lb's!!!
* Height in the open position is 34-1/4".
* Height in the Closed Position is 25-1/2".
* Width of the widest Claw is 18-3/4".
* Jaw Steel thickness is .85".
* Grapple weight is 775lb's.
* Maximum Load is 26,400lb's.
* Max Working Pressure is 4640psi.
* Torque Rating is 1900ft lb @ 2900psi.
