Spectral dynamics SD340 micro fft signal analyzer
Spectral Dynamics SD340 Micro FFT Signal Analyzer
Powers Up, appears fully functional but not fully tested.
Shown with a 1Khz sine wave applied and the a square wave to show harmonics. Time Display (scope mode) operational.
Cursor function works, frequency, volts, db.
Also includes a full operators/service manual with schematics, and front cover.
Real Time FFT Signal analyzer often used for vibration analysis.
5 Frequency ranges, 100Hz to 20 KHz FS
