New ametek~(3) ea liquid filled pressure gauges~200 psi~
AMETEK~(3) ea Liquid Filled Pressure Gauges~200 PSI~NEW
Description: This listing features a lot of (3) each Ametek Model 12909120-1 200 psi Liquid Filled Pressure Gauges. We acquired these from the U.S. Military and they are all new in their original boxes. These are not old stock and were manufactured around 2003 or 2004. Here are the specs according to the Military NSN number:
* ACTUATION TYPE: BOURDON TUBE
* ACTUATING ELEMENT MATERIAL: PHOSPHOR BRONZE
* SCALE RANGE: 0.0 TO 200.0 POUNDS PRESSURE PER SQUARE INCH
* SCALE ACCURACY: PORM 2 PCT MIDDLE, 3 PCT REMAINDER
* SCALE INSCRIPTION/BACKGROUND COLOR: BLACK MARKINGS ON WHITE COLOR BACKGROUND
* CASE MATERIAL: STEEL, STAINLESS
* OVERALL DIAMETER: 2.72" NOMINAL
* OVERALL DEPTH: 1.2" NOMINAL
* PROTECTIVE CRYSTAL MATERIAL: PLASTIC
* CONNECTION LOCATION: BACK, LOWER
* CONNECTION SIZE: 0.25" NPT DIA
* MOUNTING METHOD PANEL FLANGE
Manufacturers Re-Order Number: 12909120-1
