Eagle Technology PCI-703-64A 64-Channel PCI Analog Input
You can get a complete spectrum of data-acquisition functions with only a single board. The PCI-703-64A board provides 64 channels of analog input data with 3 counter/timers, 18 DIO lines, deep 4096-sample FIFOs, and independently programmable gains per channel. This DA model also includes two channels of 14-bit analog output with the ability to generate output waveforms.
This item is also offered in store and may be removed from here at any time.
If you need a different board, a cable, or a terminal panel for this board, please send me an eMail
5 us to 2 LSB, 15 us to 1 LSB.
Channel/gain queue lets you choose order and gain setting for channel sampling.
10 Gohms in parallel with 100 pF maximum.
* Input protection +/- 25 V with power on
* Input protection +/- 35 V with power off
* Data Transfer via programmed I/O, interrupts, and bus-mastering DMA.
Maximum working voltage is +/- 11V relative to analog ground. Do not attempt
unipolar inputs higher than 10V, even with gain range set to 0.25.
Software trigger (software-controlled trigger)
External pulse trigger (triggered by pulse on trigger input)
Analog slope trigger (trigger based on slope of acquired data points)
Counter/timer trigger (triggered by on-board counter/timer)
Number of Analog Output (D/A) Channels
Data transfer via programmed I/O, interrupts, and bus-mastering DMA.
Current - Input Voltage High (Iih)
Current - Input Voltage Low (Iil)
Counter/Timer Special Features
* High level output current: 4 mA.
* Low level output current: -24 mA.
DIO (and all other signals) appear on a 100-pin female SCSI connector on the backplate of the board.
Input Voltage - High (Vih, DC)
High level output current 4 mA.
Includes the enhanced EDRE software applications builder.
EDRE makes it possible to develop an application in one 32-bit Windows OS and then export it to another without recompiling it. This package also includes drivers for LabVIEW , TestPoint , and Agilent VEE .
Operating System Compatibility
100-pin (SCSI II style high-density D-sub, clips)
