16" NIKON V-16E VERT PROJECTION OPTICAL COMPARATOR
16" NIKON VERTICAL PROJECTION FLOOR MODEL
* THIS MACHINE HAS SO MANY OPTIONS - HOLY COW! *
** "QUADRA-CHEK 2000" DRO w/PROGRAMMABLE
GEOMETRIC FUNCTIONS & EDGE DETECTION **
MODEL: V-16E S/N: 12496 NEW: 1990's
Diameter of Screen:................................. 15.7"
Measuring Stage - Model VA:.................... 18.1 x 10.2:
-Long. Table Travel:................................ 8.9"
- Cross,Table Travel:................................ 3.0"
Size of Glass Insert in Table:.................... 11.4" x 7.1"
Max. Weight of Workpiece on Stage:......... 44 lbs (approx)
Max. Specimen Height:............................. 5.9"
Floor Space: 40" L-R x 43" F-B x 74" High
"QUADRA-CHEK 2000 SERIES" 2-Axis Digital Readout Display
with Programmable Geometric Functions & Edge Detection
(Model #2205-NL-MT, S/N: 39724)
DRO has .00005 Resolution on both Axes (50 Millionths)
Large Stage (NIKON Model 9VA) w/Rectangular Glass
Handwheels on Stage for Moving Stage L-R & F-B
Handwheel Above the Lens Turret for Moving Whole Stage
5X,10X, 20X & 50X,100X Lenses Come with the Machine
Electrical - 1/60/100-120 Volt AC
1) External light - Fiber-Lite
1) Quadra Chek III DRO with Edge Detection &
handheld key pad, manuals for Quadra Chek
1) Nikon 4" x 5" Polaroid attachment (fits over screw)
Assorted Test & Calibration Blocks
(Nikon Authorized Sales & Service)
* INSPECT UNDER POWER IN OUR HARRISON, NJ WAREHOUSE *
* EXCEPTIONAL CONDITION & APPEARANCE (ORIGINAL PAINT) *
