Hydraulic two 2 stage pump 11 gpm logsplitter hi lo
HYDRAULIC TWO STAGE PUMP 11 GPM HI LO IDEAL FOR LOGSPLITTERS
New Hydraulic Log Splitter Pump 11 GPM @ 3600RPM.
Flow rates on the hi-low tandem pumps are 3.6 cc/rev on the low flow and 8.8 cc/rev on the high flow pump.
Please check our current delivery time on this item before purchasing.
This 2 stage pump can give you much faster cycle times and higher possible pressures with a small engine.Excellent for use on log splitters. 85% efficient.
Use this pump in combination with a 6.5hp petrol engine.
Model GP-CBN is a HI/LO hydraulic gear pump with 12 different displacement combinations with maximum pressures of 900 psi for the low pressure pump and 3000 psi for the high pressure. The change from LO to HI pressure is automatic with the LO side pressure pre set from 400 psi to 900 psi.
The HI/LO section of the pump is all aluminium and the end plates are cast steel. Applications for the HI/LO pump are log splitters, presses etc where rapid movement of the cylinder at low pressure is required prior to automatically switching to the high pressure mode to meet load requirements.
Recommended working conditions
* Filtration 25 micron or better
* Oil Viscosity 6 to 200 cSt
* Inlet Pressure 12 to 32 psi abs.
* Oil Temperature -25 to 80 degrees C (-12 to 175 degrees F)
* Ambient -22 to 55 degrees C (-8 to 130 degrees F)
* Displacement (cu.in/rev) X speed (rpm) /231
