5-wire lcd touch screen usb controller
5-wire Resistive LCD Touch Screen USB Control
+5VDC (max. 100mA, typical 70mA, 50mV peak to peak max ripple)
1. RS232: 9600 bauds, None parity, 8 data bits, 1 stop bit
UL, UR, COM, LR, LL/UL. UR, COM, LL, LR
50 ~ 200 ohm (pin to pin on the same layer, touch under 1.2k ohm)
Fast Full oriental 4 points position
1. Accuracy 25 points linearity position
Position and linearity verification
1. Support multiple controllers
2. Dynamical add/ remove controllers
3. Change controller interface without reboot
Support 10 languages for Windows
1. Right/ left button emulation
1. Configurable double click speed
2. Configurable double click area
Windows 95, 98, ME, NT4/ 2000/ XP/ XP Tablet PC edition
Windows CE 2.12/ 3.0/ .net/ 5.0
640x350, 640x480, 800x600, 1024x768 and 1280x1024
1. Support COM1~COM256 for Windows and Linux
1. Support monitor/ display rotation
