Tg-UV2 dual band radio uhf + vhf + fm radio tguv ham
TG-UV2 Dual band (VHF + UHF) radio
FM: 88-108MHz (RX) VHF: 136-174MHz (RX/TX) UHF1: 350-390MHz (RX/TX) UHF2: 400-470MHz (RX/TX) UHF3: 470-520MHz (RX)
* Dual frequency display of the LCD
* PC programme or keypads programme
* Power output: High 4w Medium 2w Low 1w
* Emission Current: 1.5A
* Modulation sensitivity: 12mV
* Modulation Distortion: <5%
* Modulation Limiting : Wide <5KHz Narrow <2.5KHz
* Modulation Mode: 16 F3E 11K F3E
* Remanent Radiation 7 w
* Preemphasis character : 6dB
* CTCSS/DCS Frequency Deviation :0.75KHz 50Hz 0.37KHz 30Hz
* RF Sensitivity: -122dBm(12dB SINAD)
* Modulation Receiver Bandwith: 5KHz
* Audio Distortion: 10%
* Spurious response rejection: 65db
* Dimensions: 110mmx 56mmx 37mm
1x Desktop Charger ( 100V ~ 240V ) with correct adapter for your country
