Honeywell pull safety micro switch CBLSB1T4D+cables
Honeywell Pull Safety Micro Switch CBLSB1T4D+Cables
This is a Used Honewell Cable Pull Limit Switch PN: 2CLSB1T4D. This item includes the switch, 2 cables, and hooks. The item was pulled from a working environment but has not been tested by us. Cosmetically, the unit is in fair condition with no major damage. It has minor nicks and scratches the backside as photos show. The photos are of the actual item for sale. Only what is shown in the photos is included.
* Cable Lengths: (1)-86' / 26.2 Meters, (1) 3.2' / 1 Meter
* Mechanical life: 25000 operations maximum
* Degree of protection: IP 67 NEMA/UL type 1, 3, 4 and 13
* Temperature Operatingrange : -1 C to +70 C / 30 F to 158 F
* Directives Compliance: The forced disconnect mechanism on normally closed contacts conforms to IEC 60947-5-1-3. This product complies with the Machinery Directive 98/37/EC and complies with EN 60947-5-1
* Approvals and compliance Operating rating:IEC/EN 60947-5-1 and EN 418 Emergency stop device, UL listed, CSA certified CE marked.
* AC:15 U = 600 V: I = 1,2 A
* DC13 U = 250 V: I = 0,27 A
