12" swg 24" strk parker-majestic #1 id grinder, power t
12" Swg 24" Strk Parker-Majestic #1 ID GRINDER, POWER T
12" Swing 24" Stroke Parker-Majestic #1 ID GRINDER, POWER TABLE
PARKER-MAJESTIC "SUPER-PRECISION" INTERNAL GRINDER
MODEL: #1 S/N: 2364-1-INT-80 NEW: 1980
SWING OVER TABLE ........................ 12"
TABLE WORKING SURFACE ................... 5" X 41"
TABLE SWIVEL ............................ 7 DEGREES
TABLE TRAVEL ............................ 24"
INFINETLY VARIABLE TABLE SPEEDS ......... 3" TO 30" IPM
CROSS FEED TRAVEL ....................... 3- 1/2"
CROSS FEED ADJUSTMENT ................... 4"
CROSS FEED HANDWHEEL GRAD. .............. 0.0005"
CROSS FEED PRECISION DIAL GRAD .......... 0.000050"
HEADSTOCK SWIVEL ........................ 0 TO 90 DEG.
INFINETLY VARIABLE HEADSTOCK SPINDLE
SPEEDS ................................. 25 TO 450 RPM
HOLE THRU SPINDLE ....................... 1- 1/4"
HEADSTOCK CENTER TAPER .................. #6 JARNO
SPINDLE MOTOR ........................... 1- 1/2 H.P.
APPROX. DIMENSIONS ..................... 69"L X 37"D X 57"H
APPROX. MACHINE WEIGHT .................. 3,750 LBS.
ELECTRONIC INFINITELY VARIABLE SPEED CONTROL FOR TABLE
ELECTRONIC INFINITLEY VARIABLE SPEED CONTROL FOR WORKHEAD
TEFLON COATED LONGITUDINAL WAYS
WORKHEAD ACCEPTS 5C COLLETS W/SCREW-TYPE DRAW BAR
.00005" CROSS FEED DIAL GRADUATIONS
PARKER-MAJESTIC INTERNAL GRINDING SPINDLE
