Sadelco minimax 800 signal level catv meter mini max
* Sadelco MiniMax 800 Signal Level CATV Meter
* Carrying Strap Soft Carrying Case
Sadelco MiniMax 800 Signal Level CATV Meter
Sadelco MiniMax 800 Signal Level CATV Meter Accurate Under All Conditions
* Internal White Noise Generator
* Guaranteed + 1dB accuracy, + 0.5 typical.
* Average Power of QAM Signals
* New Neverbreak "F" Connector
* Saves Battery Power and Increased Time Between Charges
* C/N: Range > 50 dB with external preselector
* Hum: 0.5 - 5%, 0.3%, detects all hum up to 600 Hz.
* Favorite Channels: 9 user Programmable Channels.
* Delta PA: Automatically calculates and displays difference between picture and audio levels of same channel.
* Audio: Adjustable volume, waterproof mylar speaker.
* Illumination: Switchable lights for night work
* Battery Test: Shows battery voltage and elapsed time
* Power Supply: Built-in NiCads provide >16 hrs of normal intermittent use
* Electronic Shut-Off: User adjustable, 5 min, 10 min or continuous
* Digital Channel Measurement: Measures average power of QAM signals
* Frequency Range: 5 - 872 MHz
* Standard Channel Plans:EIA (NTSC), HRC, IRC, AIR-VHF, UHF, FM, PAL and
* Custom Channel Plans available on request.
* Channel Mode: 6, 7, or 8 MHz
* Frequency Accuracy: 20 KHz
* IF Bandwidth: 280 KHz at 3dB points
* FM Selectivity: Will distinguish 2 FM signals of similar amplitude 300 Khz apart
* Measurement Range: -30 to +50 dBmV (+30 to +110dBuV)
* Amplitude Accuracy; 1.0 dB at 77 F; 2.0 dB from 0 - 120 F
* Auto Calibration: Each measurement computer corrected for level, attenuator setting and temperature
* Internal Calibrator: 0.25 dB, 4.5 - 864 MHz white noise source
* Range: 40 dB autoranging, computer corrected
* Input: 75 ohm, user replaceable F81 connector, BNC available on request.
* Digital LCD: Indicates channel, frequency and signal level in dBmB (switchable to dBuV)
* Weight: 3.1 lbs (1.4 Kg), including case and batteries.
