Stepper motor speed pulse controller & driver board
Stepper Motor Speed Pulse Controller & Driver Board
- 100% Brand New Stepper Motor Speed Pulse Controller & Driver Board
- Matching motors: 6 wires or 4 wires stepper motor (2-phase)
- Voltage (stepper motor): 9-40VDC
- Motor speed adjustable and can be retained
- Common Empty if 6-wire motor
- Pulse and Signal Control Mode:
- Input pulse: CP (can adjust step motor speed)
- Directional signal: DIR (high voltage=INC; low voltage=DEC)
- With jumper JP2 mounted: INC=CW run, DEC=CCW run, FUN=Stop
- With jumper JP2 removed: INC=Accelerate, DEC=Decellerate, FUN=Speed memory
- (If you mount jumper JP2 after speed adjustment it will be memorized, even when power is off)
- Dimensions: Width 46mm (1.8in), Length 70mm (2.7in), Height 30mm (1.2in) .
