Lot (13) dpdt miniature toggle switches on-on-(on) jbt
Only THREE lots of THIRTEEN remaining!
Offered here are lots thirteen JBT (now Eaton) miniature size toggle switches. DPDT,
but in a highly unusual on-on-(on) configuration. The leads are also an extra long
11/16 of an inch. These were intended for wirewrapping but might prove very useful
if you want to extend a switch well above a printed circuit board.
Here is how the switch action works. There is a sustained left position, a sustained
center position, and a momentary spring return right position.
In the sustained left position, both sides have their left contacts made...
In the sustained center position, one side has its right contact made
In the momentary right position, both sides have their right contacts made...
The toggle blade is round, measuring 7/16 inch overall. Body measures 3/8 inch
by 7/16 inch by 1/2 inch, less terminals. Green switch body. 25 mil square gold
Guaranteed usable. Received by us in "as new" distributor repackaged single poly baggies.
Includes two mounting nuts and two washers. Switches guaranteed pristine; outer
poly bags may include storage cosmetics.
offering the above unusual switching pattern..
for the first lot of 13 and $1 extra for each additional lot of 13. AZ residents add 8.1% sales tax.
