New yaskawa servopack sgdh-01AE , sgdh-01AE YA11 sigma
input 200-230 VAC single phase 24 Amp
http:// /site/products.nsf/products/Servo%20Systems%20and%20Motion%20Controllers~SGDHSigmaII.html?OpenDocument&Source=SearchResultPage
Yaskawa Electric America, Inc is pleased to announce the expansion of the Sigma II Series servo system with the Sigma FSP amplifier. FSP stands for Flexible ServoPack and is built on the proven Sigma II SGDH amplifier power platform. This new amplifier provides built-in position control for simple indexing applications, electronic gearing, and cam profile following, in addition to the standard analog and pulse input of the Sigma II Series. The FSP positioning mode employs Yaskawa's latest generation of real-time adaptive tuning, which dramatically reduces following error and settling time. FlexWorks, the FSP setup software, features single-button auto-tuning, digital oscilloscope, FFT mechanical analysis, and wizard set-up of amplifier mode, units, and I-O.
In conjunction with the Sigma FSP release, Yaskawa Electric America announces the Special Purpose Motor Program, whereby Yaskawa and Elwood-Gettys have partnered to supply tested and documented servo amp/motor combinations for severe duty washdown and explosion-proof applications.
The Sigma II Amplifier is the ultimate servo solution for your automation needs. A single platform covers 30 watts to 55 kW and input voltages of 200-230 VAC and output voltages of 0-230 VAC. The Sigma II amplifier can be set to torque, speed, or position control. A single-axis controller and a variety of network interface modules can be attached to the amplifier for the utmost flexibility. The Sigma II amplifier utilizes serial encoder technology to automatically recognize Sigma II rotary and linear servomotors. Advanced algorithms provide high performance tuning and suppression of machine resonance. A built-in keypad and serial port allow easy set-up and monitoring of the servo system. SigmaWin and SigmaWin Plus software can be used to capture torque, speed, and command references and SigmaWin Plus Professional can perform FFT and machine simulations.
