Murphy direct mount pressure switch psb-75-F15 0-75PSI
MURPHY Direct Mount Pressure Switch PSB-75-F15 0-75PSI
The PSB switch is a direct mount switch for critical pressure points. It has one limit contact that can be used to activate an alarm, actuate indicator lights, or shut down equipment. Construction is the same as the time-proven Murphy Switchgage. The housing is weather sealed to prevent entry of moisture, dust, etc. The PSB is ideal when reading is not desired, but pressure is critical to operational efficiency.
* Factory pressure setting: 15PSI
* Contact rating: SPDT 3A @ 30VDC
* Case outside diameter: 2-1/4"
* Pressure connection: 1/8-27NPT brass
* Diaphragm: formed beryllium copper
* Pulsation damper: brass, removable for cleaning
* Terminal block: 3x 4-40 screws
* Temperature range: Ambient -40 F - 150 F, Operating: -40 F - 250 F
* Mounting orientation: Horizontal to vertical, inlet DOWN
* Fits all engine applications
* Activates indicator lights, alarms, or shut down equipment
* Easy wiring terminal block
* Steel housing specially coated to resist corrosion
