Hp agilent 1661A 102 ch 250/500 mhz la refurbished
HP Agilent 1661A 102 CH 250/500 MHz LA Refurbished
The 1661A 102 Channel Logic Analyzer features a new CPU design that improves performance and adds PC style mouse and keyboard connections, hard disk drive, printer interface and optional Ethernet LAN.
* State and timing channels: 102
* Setup/hold time: 3.5/0 ns to 0/3.5 ns
* State/timing memory depth: 4k on all channels, 8k on half channels
* Timing analysis modes and speeds (conventional): 250MHz on all channels, 500MHz on half channels
* Timing analysis modes and speeds (transitional): 125MHz on all channels, 250MHz on half channels
* Timing analysis modes and speeds (glitch): 125MHz on half channels
* State analysis speed: 100MHz
* Minimum detectable glitch width: 3.5 ns
