Microe SA200 2-axis high performance servo amplifier
MicroE SA200 2-Axis High Performance Servo Amplifier
For Use with PA-2000 Series Positioning Systems
The SA200 Servo Amplifier is a dual channel transconductance amplifier
which drives the primary position loop and the product actuator in the HDA.
The transconductance gain of each channel can be factory configured
between 0.005A/V and 0.2 A/V, to accommodate a range of voice coil motors.
The input signal bandwidth of each channel can be set up between 1 KHz and
20 KHz, and is nominally set at 10KHz.
Each channel has a user programmable
universal active filter and features an opto-isolated TTL level enable
command to prevent ground loops.
