TSC Conflict Monitor 16 Channel Model 210MV
* Used 16-channel conflict monitor
* My vendor replaced these TSC brand conflict monitors with EDI (Eberle Design Inc.) brand conflict monitors.
* Documents accompanying my purchase show these conflict monitors are maintained, tested and certified.
* The service records I received with 125+ of these conflict monitors indicate product retirement rather than product failure.
* This seller is not qualified to test or certify conflict monitors.
This vendor complies with the federal warranty law: Magnuson-Moss Warranty Act.
The following presention is directly from the maufacture's web site:
Model 210MV Features and Specifications
* Compatibility with all TYPE 170 and TYPE 179 Controllers
* RS232 Serial Communications Capability
* DIP Switch selection of Enhanced Monitoring Functions
* Systems Communications through Controller Unit as an option
* RMS voltage monitoring (not peak-voltage-only)
* Internal monitor Hardware and Software Watch Dog
* Event Logging of records retained through power failure
* Enhanced Monitoring including Red Monitoring
* Simple command/routine enables all functions for automatic testing while retaining desired set-up for intersection
* Displaying permissive programming on Personal/Laptop Computer
* Easier Monitor Programming
* Accurate Record Keeping and Data Logging
* Improved Intersection Operation and Efficiency
In accordance with Type 170 Specifications
89 to 135 volts ac, or as per applicable specification.
60 +/- 3 Hertz 1 Amp SLO-BLO fusing
-34 C to +74 C Operating -50 C to +85 C Storage
16 Channels, 18 optional - add "-18" to model number.
Controller Watch Dog, 1.0 seconds or 1.5 seconds. 48 ac field wire voltages (both polarities of sinusoid and out-of-phase voltages are monitored). 54 as an option, ("-18")
All active channels, power, and FAULTS on LEDs.
`RESET' button prevents defeating unit operation
Conflicting Green or Yellow on any two or more non-compatible channels (full or half-wave). FAULT signal status retained through power failure in EEPROM and displayed on LED indicators.
Minimum Yellow Timing, Sequence and Multiple Output monitoring selectable for each channel. Absence of Red selectable for each channel. Selections made using DIP switches. Low (Brownout) and high AC line voltage. Internal monitor Hardware and Software Watch Dog. Failure due to removal of program card.
Meets CALTRANS TYPE 170 requirements. Performs RMS (not peak) and out of phase voltage monitoring for Green, Yellow and Red inputs. Supplied with Model 210-DC Diode program card for programming permissives and Yellow inhibit. Uses internal Menu-driven Set-up Program and DIP switches for making monitoring selections by channel. Example of Event Log print-out below.
SITE FFFF 00FF DATE 12/16/94 TIME 18:26:32
LAST SETUP CHANGE 12/16/94 18:13
LAST TIME/DATE CHANGE 12/10/94 08:34
EVENT LOG OVERFLOW 08/22/94 08:36
001 08/22/94 08:33 GGGGRRRRYYYYGGRR TRANS FAIL 4G 4R
002 07/15/94 23:20 CONTROLLER RESET
004 07/15/94 20:23 RRRRYYYYGGGYYRRR POWER FAIL
005 06/05/94 12:18 YYYYGGRRGGRRRRRR WATCH DOG FAIL
The above presention is directly from the maufacture's web site.
