14" jones & lamson epic 14S optical comparator, qc 220
14" Jones & Lamson Epic 14S OPTICAL COMPARATOR, QC 220
14" Screen Jones & Lamson Epic 14S OPTICAL COMPARATOR, QC 2200-AR DRO, PROG. GEO. FUNCT. & EDGE DETE
14" JONES & LAMSON (MADE IN VERMONT) OPTICAL COMPARATOR
QUADRA-CHEK DIGITAL READOUT MODEL 2200-AR (S/N: 24069),
2-AXIS DISPLAY, FEATURING PROGRAMMABLE GEOMETRIC FUNCTIONS
MODEL EPIC 14S S/N: 81537 NEW : 1997
SCREEN DIAMETER........................... 14"
TABLE SIZE................................ 6" X 30"
MEASURING CAPACITY (TABLE TRAVEL)
LONGITUDINAL: ............................ 9"
VERTICAL:................................. 8"
ANGULAR MEASURING CAPACITY.... 360 DEGREE CHART ROTATION
CROSS TRAVEL FOR FOCUSING................. 3"
HELIX ROTATION-TABLE SWIVELS.. 15 DEGREES LEFT & RIGHT
DISATANCE, LENS CENTERLINE TO TABLE ...... 1" MINIMUM
FLOOR SPACE .................... 46" L-R X 67" F-B x 81" H
APPROX. WEIGHT ............................2,900 LBS.
POWER LONGITUDINAL TABLE TRAVEL
SIX POSITION POWER LENS TURRET
(3) LENSES .... 10X, 20X & 50X MAGNIFICATIONS
NOVALITE MERCURY ARC PROJECTION
& RS-232 INTERFACE FOR DOWNLOADING STATISTICAL DATA
** ORIGINAL PAINT - EXCEPTIONAL CONDITION & APPEARANCE **
