42" tbl 3HP spdl clausing-kondia fv-1 vertical mill, va
42" Tbl 3HP Spdl Clausing-Kondia FV-1 VERTICAL MILL, Va
42" Table 3HP Spindle Clausing-Kondia FV-1 VERTICAL MILL, Vari-Speed, Acu-Rite DRO,R-8,Servo Power F
CLAUSING-KONDIA VERTICAL MILLING MACHINE
MODEL: FV-1, S/N: Z-63, NEW: 1995
LONGITUDINAL TABLE TRAVEL ............. 36"
SADDLE TRAVEL ......................... 15"
KNEE TRAVEL ........................... 16.5"
RAM TRAVEL ............................ 23"
TABLE LOAD CAPACITY ................... 880 Lbs
MIN/MAX DISTANCE, SPINDLE NOSE TO TABLE 6-5/8" / 29-11/16"
TP FACE OF COLUMN ............... 0" / 18-5/16"
INFINITELY VARIABLE SPEED RANGE ....... 60-4,000 RPM
QUILL DIAMETER ........................ 3-3/8"
QUILL FEEDS ...................... 0.0015", 0.003", 0.0047"
APPROXIMATE WEIGHT .................... 3,040 LBS
SPACE REQUIRED FOR OPERATION .......... 78" F-B
ACU-RITE MILLMATE 2-AXIS DIGITAL READOUT
SERVO POWER FEED FOR LONITUDINAL TABLE TRAVEL
HARDENED & GROUND TABLE AND WAYS
BIJUR ONE-SHOT LUBRICATION SYSTEM
3 HORSE POWER VARIABLE SPEED MILLING HEAD
